The Pre-Shipment Control Panel Checklist We Use Before Crating
A control panel can pass FAT and still arrive on site with a problem that should have been caught before packing.
The cause is usually not a major design failure. More often, the panel was changed after FAT, one terminal was never rechecked, a VFD parameter remained at its temporary test value, or the drawing packed with the cabinet no longer matched the panel that actually shipped.
This is why we treat pre-shipment inspection as a separate release gate from FAT.
FAT answers an important question:
Does the control panel operate according to the agreed control philosophy?
The pre-shipment checklist answers another one:
Is the panel we are about to crate the same panel that was tested, documented and approved?
For buyers sourcing a custom control panel, PLC control panel, VFD panel, or OEM control cabinet, that final distinction matters. A ten-minute correction on the workshop floor can easily become a day of troubleshooting after the panel reaches another country.
What Should a Pre-Shipment Control Panel Inspection Actually Verify?
The checklist does not need to repeat every FAT test.
Its purpose is to close the gap between finished testing and physical shipment.
We normally divide the review into five areas:
Pre-Shipment Area | What We Verify | What Can Happen If It Is Missed |
|---|---|---|
Enclosure and mechanical build | Doors, cutouts, mounting, gland plates, hardware, and enclosure condition | Site modification, water ingress, or installation problems |
Wiring and terminals | Wire labels, terminal numbers, power connections, and earthing | Wrong field connections, loose terminals, or startup faults |
PLC / HMI / VFD configuration | Released software and final device parameters | Wrong program version or first-start trips |
Interface information | I/O, communication settings, and cable entries | Field wiring and network mismatch |
Documentation | As-built drawings, backups, manuals, and FAT records | Slow troubleshooting and unclear responsibility |
This is not a cosmetic inspection.
The objective is to verify that the physical panel, software configuration, and documentation still agree with each other when the crate is closed.
1. Start With the Panel That Will Actually Be Shipped
By the time FAT is complete, most buyers assume the cabinet is finished.
In OEM projects, that is not always true.
A customer may request an additional signal after FAT. A terminal may be moved because the outgoing cable route changed. A breaker rating may be corrected. A gland plate may be modified after the final cable schedule arrives.
None of these changes is unusual.
The risk comes when the modification is completed physically but not carried through the rest of the project information.
Before crating, we therefore compare the actual cabinet with the latest approved drawings rather than relying on the original production package.
For the enclosure itself, that includes checking:
- cabinet dimensions and mounting arrangement;
- door, hinge, and lock operation;
- gland plates and field-entry locations;
- equipment mounting and mechanical security;
- earthing and bonding;
- gasket condition;
- visible damage to coating or stainless surfaces;
- enclosure rating details where required by the project.
For an outdoor IP65, IP66, or NEMA-rated control panel, this is also the last practical opportunity to confirm that fabrication changes have not compromised the intended environmental protection.
2. Wiring Is Checked Against the Drawing, Not Against Appearance
A neatly wired cabinet can still contain a wiring error.
That is why visual workmanship and electrical verification should not be treated as the same inspection.
Before shipment, critical wiring should be checked against the as-built schematic and terminal schedule.
We pay particular attention to:
- field terminal numbers;
- wire markers;
- power and control separation;
- PE and grounding connections;
- shield termination;
- motor and VFD connections;
- safety circuits;
- external interface terminals.
Power terminals deserve their own check because a connection that feels tight by hand is not necessarily tightened to the required torque.
For high-current circuits, VFD feeders, motor terminals, and major distribution points, the final inspection should confirm that the relevant connections were tightened according to the component requirements and that no production work was performed afterwards that could have disturbed them.
This sounds basic, but it is exactly the kind of issue that becomes difficult to diagnose after the cabinet has been installed inside a machine.
3. Verify the Software Version That Is Leaving the Workshop
Another failure mode is surprisingly simple: the panel works during FAT, but the program shipped in the PLC is not the same released version that the buyer approved.
This can happen when engineers keep several revisions during debugging.
For example:
Project_Final
Project_Final_2
Project_Final_New
Project_Final_FAT
By the end of commissioning, nobody should be relying on filenames like these to identify the final program.
The pre-shipment check should confirm the release:
- PLC program;
- HMI project;
- VFD parameters;
- communication settings;
- safety-controller program where applicable.
Where the platform supports it, version information or checksums should be recorded.
The buyer should also receive a backup of the released files as part of the handover package.
For a PLC control panel supplier, this is not simply good document management. It gives the customer's commissioning engineer a known starting point when troubleshooting later.
4. VFD and Protection Settings Need a Final Reality Check
A drive can communicate perfectly during FAT and still trip immediately when connected to the actual motor.
The reason is often that the temporary FAT settings were never replaced with the final project values.
Before shipping a VFD control panel, we want to know whether the following have been confirmed from the motor and application data:
- rated voltage;
- rated current;
- base frequency;
- control mode;
- acceleration and deceleration time;
- minimum and maximum speed;
- motor protection settings;
- relevant communication address.
Not every parameter can or should be finalized in the workshop.
Some process tuning must happen during site commissioning.
That is acceptable as long as the distinction is documented.
A good pre-shipment record should make it clear which parameters have already been configured and which ones remain intentionally open for SAT or commissioning.
Otherwise, “to be set on site” easily becomes “everybody thought somebody else had already set it.”
5. The As-Built Drawing Is Part of the Panel
The most important document in the crate is usually not the original quotation drawing.
It is the final as-built electrical schematic.
If a field technician opens the cabinet six months later, the drawing should tell him what is physically in front of him.
That means the documentation pack should reflect:
- final terminal numbers;
- final wire numbers;
- actual installed components;
- last wiring changes;
- current PLC I/O allocation;
- final communication addresses where documented;
- final drawing revision.
For custom OEM panels, we also normally expect the final package to include the I/O list, FAT report, equipment manuals, software backups, and recommended spare-parts information.
The test records tell the buyer that the panel worked.
The as-built documentation tells the buyer how the panel is actually built.
Both matter.
Pre-Shipment Release Decision Matrix
Not every open item should block shipment.
The important point is to distinguish between something cosmetic and something that may create a commissioning problem.
Finding Before Crating | Ship? | Engineering Decision |
|---|---|---|
Missing wire label | No | Correct and recheck against schematic. |
Incorrect as-built drawing | No | Update before release |
Unconfirmed power-terminal torque | No | Verify before crating. |
Wrong VFD motor parameters | No | Correct or document required site setting |
Minor paint touch-up required | Usually after correction | Does not normally require functional retest |
Missing spare-part manual | Hold documentation release. | Complete the handover pack before shipment. |
HMI text typo with no control impact | Project dependent | Correct if time permits; document if accepted. |
Open safety or interlock issue | No | The panel should not be released. |
The cable gland does not match the confirmed field cable | No | Correct before shipment |
The purpose of the matrix is simple: shipment approval should be based on startup risk, not on how close the delivery date is.
Example: A Panel That Had Already Passed FAT
On one representative OEM project, the control panel had completed FAT without a major issue.
The PLC sequence had been demonstrated, the HMI worked correctly, and the customer had approved the test record. Packing was scheduled for the following morning.
During the pre-shipment check, the engineer compared the final terminal arrangement with the latest field cable schedule.
One motor feeder had been revised after FAT because the customer changed the motor cable size. The new cable required a larger gland, and the gland plate had been modified accordingly.
The modification itself was correct.
The problem was that the terminal drawing and gland schedule in the document pack still showed the previous revision.
If the cabinet had shipped that afternoon, the machine probably still could have been commissioned. But the site electrician would have received a drawing that disagreed with the cabinet in front of him, and the purchasing team would have had to request corrected documents after delivery.
The panel was held for several hours.
The as-built drawing was updated, the terminal and gland schedule was checked again, and the final document pack was regenerated before crating.
Nothing dramatic happened.
That is exactly the point.
The best pre-shipment inspection often prevents problems that nobody ever hears about later.
FAT and Pre-Shipment Inspection Are Not the Same Thing
Buyers sometimes ask why a separate checklist is necessary if the panel has already passed FAT.
Because the two activities answer different questions.
FAT verifies function.
It confirms that the PLC logic, HMI operation, alarms, interlocks, communication, and control sequences behave according to the agreed test scope.
Pre-shipment inspection verifies release condition.
It confirms that the panel has not drifted away from the tested configuration and that the physical build, software, and documentation are ready to leave together.
For an OEM control panel manufacturer, both controls are important.
A panel that passes FAT but ships with outdated documents creates unnecessary commissioning risk.
A panel with perfect documentation but untested control logic is no better.
What Buyers Should Ask a Control Panel Supplier Before Ordering
When comparing custom control panel manufacturers in China, it is worth asking what happens between FAT approval and shipment.
Useful questions include:
- Is there a documented pre-shipment inspection?
- Who signs the release?
- Are final wire labels checked against the as-built drawing?
- Are power terminals torque-verified?
- Is the released PLC/HMI program version recorded?
- Are VFD parameters documented?
- Are the final electrical drawings included before shipment?
- Can inspection photos and records be shared remotely?
- What happens if an item fails the release check?
These questions often tell you more about a control panel supplier's quality discipline than a factory photo or component brand list.
Common Mistakes
❌ Treating FAT approval as automatic shipment approval.
❌ Updating the physical panel after FAT without updating the as-built schematic.
❌ Checking whether terminals look tight instead of verifying critical power connections properly.
❌ Shipping PLC, HMI, or VFD software without recording the released version.
❌ Assuming the buyer can sort out missing documents after the cabinet arrives.
❌ Comparing OEM control panel quotations without checking whether FAT, final inspection, and documentation control are actually included.
Engineering Takeaway
A pre-shipment control panel checklist should not repeat the entire FAT.
Its job is narrower and commercially much more useful: confirm that the cabinet being crated is the same cabinet that was tested and that the buyer will receive the correct documentation with it.
For an OEM buyer, this is one of the lowest-cost places to reduce commissioning risk.
Once the panel has been packed, shipped internationally, and installed inside the machine, every correction becomes slower.
Before crating, it is still a workshop problem.
